| CONTINUOUS VOLTAGE RATING | 8 V to 35 V Continuous | VOLTAGE RANGE |
15 V to 415 V AC (Ph to N) 26 V to 719 V AC (Ph to Ph) |
| CRANKING DROPOUTS | Able to survive 0 V for 50 mS | FREQUENCY RANGE | 3.5 Hz to 75 Hz |
| MAXIMUM OPERATING CURRENT | 85 mA at 12 V, 96 mA at 24 V | MAINS (UTILITY) DSE4520 ONLY | |
| MAXIMUM STANDBY CURRENT | 51 mA at 12 V, 47 mA at 24 V | VOLTAGE RANGE |
15 V to 415 V AC (Ph to N) 26 V to 719 V AC (Ph to Ph) |
| MAXIMUM SLEEP CURRENT | 35 mA at 12 V, 32 mA at 24 V | FREQUENCY RANGE | 3.5 Hz to 75 Hz |
| OUTPUTS | DIMENSIONS | ||
| OUTPUT A (FUEL) | 10 A short term, 5 A continuous,at supply voltage | OVERALL | 140 mm x 113 mm x 43 mm |
| OUTPUT B (START) | 10 A short term, 5 A continuous,at supply voltage | PANEL CUT-OUT | 118 mm x92 mm |
| AUXILIARY OUTPUTS C,D | 2 A DC at supply voltage | MAXIMUM PANEL THICKNESS | 8 mm |
