Features :

1.H.264 High profile compression algorithm ideal for standalone NVR

2.Realtime live display up to 4 cameras

3.Pentaplex function:live,recording,playback,backup & remote access;

4.Support Dual-streams,to make mobile monitoring very easy,flexible for network transmission

5.Smart video detection:motion detection,video blind,video loss

6.Smart camera settings:privacy masking,camera lock,color setting,and tittle display

7.Easy backup methods: USB devices,remote network and client software backup

8.Alarm triggering screen tips,buzzer,PTZ preset,e-mail &FTP upload

9.Smart HDDs Management:non-working HDD hibernationg,HDD faulty alarm,Raid function

10.Powerful network software:built-in web server,multi-DVR client &SMS Networking access for remote live viewing,recording,playback,setting,system statu,event log,e-mail & ftp function

11.Support DHCP / PPPOE / FTP / DNS / DDNS / NTP / Email alarm / IP right management / IP search / network alarm center functions, support web client, standalone client and SDK.

12.With the sound system for the protection circuit, unique triple watchdog function, very low power consumption, to ensure the equipment never be hang up.

    With the unique black box technology, can monitor the whole run process of the equipment, can greatly reduce the maintenance costs.

13.Enable strong multi-way synchronization with max 1/4 channel playback, realize the zero-delay between playback channels

14. Support Standard Onvif 2.0 protocal

15.Real P2P : Cloud : XMEYE.NET ; APP :XMEYE

Specification:

Operating System：Embedded LINUX/ 3520D Main Processor

System Resources：Pentaplex function:live,recording,playback,backup & remote access

Operation interface：16-bit true color graphic menu operation interface, support mouse operation

Preview：1/4

Video Standards：PAL 625 line,50 f/s;NTSC 525 line,60 f/s

Video Compression：H.264 High profile

quality supervision：Monitor: D1; VGA: high definition; HDMI: hd

Video Recording：1080P/720P/960H/D1

Vidie input(IP)：4*1080P/8*960P

Motion Detection：

Supports

( Depends on Camera ,the front-end ip camera must have this function )

Audio Conpression：G.711a

Bidrectional Talk：N/A

Recording Mode：Manual>Alarm>Dynamic>Timing

Playback：1*1080P/4*960P

Search Mode：Time/Date,Alarm,Motion Detection & exact search(accurate to second)

Video saved：Local HDD,network

Backup Mode：Network download/Flash stick/USB/SATA

Video Output：1CH VGA output, 1CH HDMI

Net Interface：RJ-45 10M/100M
USB Interface：2* USB2.0 port for mouse and backup

Hard Disk：1 SATA port(Max 1 x 4T)

Power Supply：12V/2A

Dimension：210x 200 x 40mm

ONVIF：Standard 2.0

Usage ONE :

Usage TWO :
