Packing

product dimension

11.3x11.3x2.4cm

Packaged size

21  x14x 5.5 cm

Packaged weight

0.55kg

Loading for 20HQ

43 x29 x 28cm

System Config

CPU

S905    quad-core cortex-A53       frequency：2.0G

GPU

Mali-450           5-Core GPU

FLASH

8GB emmc

SDRAM

1GB DDR3

Power Supply

Power Supply

DC 5V/2A

Power Indicator (LED)

Power ON :blue

Main Features

Power Indicator (LED)

Plastic material  (Private model with  LED display)

OS

Android5.1

KODI

16.0

WIFI

 2.4GHz/1GB DDR3

3D

Hardward 3D graphics acceleration

Support Decoder format

HD MPEG1/2/4,H.264, HD AVC/VC-1,RM/RMVB,Xvid/DivX3/4/5/6 ,RealVideo8/9/10

Support Media format

Avi/Rm/Rmvb/Ts/Vob/Mkv/Mov/ISO/wmv/asf/flv/dat/mpg/mpeg

Support Music format

MP3/WMA/AAC/WAV/OGG/AC3/DDP/TrueHD/DTS/DTS/HD/FLAC/APE

Support Photo format

HD JPEG/BMP/GIF/PNG/TIFF

USB host

2 High speed USB 2.0,support U DISK and USB HDD

Card reader

SD/SDHC/MMC cards

HDD file system

FAT16/FAT32/NTFS

Support Subtitle

SRT/SMI/SUB/SSA/IDX+USB

High Difinition video output

SD/HD max.1920x1080 pixel

OSD type of languages

English/French/German/Spanish/Italian/ etc multilateral languages

LAN

Ethernet:Gigabit 10/100M, standard RJ-45

Wireless

Built in WiFi

Mouse/ Keyboard

Support mouse and keyboard via USB;Support 2.4GHz wireless mouse and keyboard via 2.4GHz USB dongle

HD

HD 2.0 up to 4k2k Output

4K2k hd decoding

4k2k H.265 Hardware Video Decode and 4k2k Output

1080P/AV/Dolby/3G

Support

SPDIF/IEC958

Coaxial

Software Specifications

Network Function

Skype chatting,Picasa,Youtube,Flicker,Facebook,Online movies,etc

Other feature

Free Internet searching,thousands of android applications,many kinds of games,etc.
