• Video scaler converts VGA signals to HDMI for use on modern display devices such as HDTVs, monitors and projectors | Adapter carries both audio and video signal
• Connect your older laptop and desktop PCs to HDMI equipped monitors and television sets | Also works with retro gaming consoles that support VGA such as the Sega Dreamcast (additional cable required)
• Adapter carries VGA signal to HDMI devices but preserves original video resolution | Will not upscale signal to HD resolutions simply allows legacy devices to connect to HDMI at original supported size
• Supports both video and audio signals, left and right RCA audio inputs | Adapter is not bi-directional, only carries signal from VGA to HDMI
• Package Contents: 1x VGA to HDMI converter, 1x power adapter




这款转换器能够将VGA输入转换成HDMI，这款产品主要用于HDTV展销处，高清电视，机顶盒, DVD等投影设备的工厂，数据监控中心，大型会议展示中心，学校及各个公司。
特性： 这款HDMI转换器拥有许多特性，性能优异。在这些特性中您将发现：
1.使用简单：安装迅速，无需设置;
2.转换：将PC的VGA视频和RL音频完全转换成HDMI;
3.增添VGA和RL音频输出接口可以连接到电脑的显示器和扬声器;
4.HDCP传输。
规格：信号输入输出
视频信号输入0.5-1.0 volts p-p
DDC信号输入5 volts p-p (TTL)
视频输出HDMI 1.2a
VGA 640x480 60Hz 75Hz
800x600 60Hz 75Hz
1024x768 60Hz 75Hz
1280x720 60Hz 75Hz
1280x768 60Hz 75Hz
1280x960 60Hz 75Hz
1280x1024 60Hz 75Hz
1366X768 60Hz
1600x1200 60Hz
DTVHDTV 480i576i480p576p720p1080i1080P
使用频率
数据传输频率165MHz
视频传输带宽1.65Gpbs165MHz
分辨率(HDTV)
隔行扫描(50&60Hz)480i,576i,1080i
逐行扫描(50&60Hz)480p,576p,720p,1080p
外观尺寸 尺寸(长x宽x高)89mm x 29mmx 68mm
重量(净重)0.48kgs
保修 保修期限1年

厂家VGA转HDMI转换器带音频 vga转hdmi铁盒 vga to hdmi视频1080P
