Manual hydraulic stacker
 |
本款手动液压堆高车，是一款高效、便捷、经济的轻型物料搬运设备，无需电力驱动，依托手动液压原理实现物料升降与搬运，广泛适配仓库、车间、超市、物流中转站等平整场地，专注解决中小型货物堆码、存取、短途转送需求，兼顾实用性与经济性。产品采用高强度型钢车架，结构坚固稳定，可灵活实现货物分层堆放，有效利用仓储空间。
This manual hydraulic stacker is an efficient, convenient and economical light-duty material handling equipment. It does not require electric drive, and realizes material lifting and handling relying on manual hydraulic principle. It is widely applicable to flat sites such as warehouses, workshops, supermarkets and logistics transfer stations, focusing on solving the needs of stacking, accessing and short-distance transferring of small and medium-sized goods, balancing practicality and economy.The product adopts a high-strength section steel frame, which is firm and stable in structure. It can flexibly realize layered stacking of goods and effectively utilize storage space.
|
经验丰富 |
源头工厂 |
支持定制 |
发货迅速 |
Experienced |
Source Factory |
Customization |
Fast delivery |
| 规格Model | 1吨升高1.6米 |
| 载重Capacity | 1吨 |
| 自重weight | 230kg |
| 总长Total length | 160cm |
| 整机高度Total height | 213cm |
| 整机宽度(可调节)Total width(adjustable) | 140cm/120cm |
| 叉腿外宽(可调节)Leg spread outer width | 140cm/120cm |
| 叉腿内宽(可调节)Leg spread inner width | 120cm/100cm |
| 货叉最-低高度fork lowest height | 6cm |
| 货叉长度fork length | 115cm |
| 单叉宽single fork width | 16cm |
| 货叉外宽(可调节)Outer side fork width | 82cm~32cm |
| 载重轮Load bearing wheel | 50mm*180mm |
注:以上尺寸为手工测量难免存在误差，请以收到的实物为准!
|
1、加厚锰钢车身 Thickened Manganess steel body |
|
2、叉腿宽度可伸缩 Leg width adjustable |
 |
3、加粗链条拉力大 Reforced chain,high breaking load |
4.整体油缸杜绝漏油 Integral cylinder,no oil leakage
|
（1）门框采用优质锰钢板制成的C型钢焊接结构，具有出色的刚性及高强度，能够长期使用而不易损坏。 （2）其结构轻巧灵活，转弯半径小，操作起来十分方便。非常适合用于模具加工行业、物流领域、仓库、码头、超市。 （3）通过手动推动的方式即可实现操作，无需使用提升装置，从而大大提高了工作效率。 工厂有权对材料和技术参数进行修改，请在下单前确认相关细节。 |
（1）the door frame adopts the high quality manganese plate C section steel welding,the rigidity is good,the strength is high,can be used for a long time. （2）The body structure is nimble and light,the turn radius is small,the operation is comfortable and so on the advantage,suits the mold processing industry,the logistics industry and the warehouse,the wharf,the supermarket and so on . (3) Manual foot movement can replace the operation of the lifting function,greatly improved the work efficiency. The factory reserves the right to modify the materials and technical parameters,please confirm before placing the order.
|
